Hermetic compressor Tecumseh HGA 2436Z
Tecumseh L'Unite HGA2436Z, LBP, R404A/R507
- Applications for commercial refrigeration - low temperatures.
- Single-phase electric power.
- Power supply 220-240/50/1 V/Hz/Ph
- Application LBP
- Refrigerant R404A, R507
- Displacement 12,8 cm³
- Oil volume 290 cm³
- Connection (suction) 1/2 "
- Connection (discharge) 5/16 "
- Maximum current 5,0 A
- Cooling capacity (W)/Evaporating temp. (°C)
- -35°C : 449 W
- -30°C : 569 W
- -23,3°C : 765 W
- -20°C : 878 W
- -15°C : 1071 W
- -10°C : 1295 W
| L'Unite (LBP, R404A/R507) |
| Modele |
Power supply (V/Hz/Ph) | Application | Displacement (cm³) | Cooling capacity (W)/Evaporating temp. (°C) (W) |
| -40°C | -35°C | -30°C | -23,3°C | -20°C | -15°C | -10°C |
| HGA2426Z | 220-240/50/1 | LBP | 9,5 | | 344 | 436 | 586 | 672 | 820 | 990 |
| HGA2432Z | 220-240/50/1 | LBP | 11,5 | | 426 | 537 | 716 | 818 | 993 | 1193 |
| HGA2436Z | 220-240/50/1 | LBP | 12,8 | | 449 | 569 | 765 | 878 | 1071 | 1295 |
| HGA2446Z | 220-240/50/1 | LBP | 16,1 | | 582 | 738 | 994 | 1142 | 1398 | 1696 |
Hermetic compressor Tecumseh HGA 2436Z
