Portable unit Gree Shiny 12000 BTU (R410A)

Flexible technology for homes and offices

  • High energy efficiency.
  • High loading protection, overload protection, anti-freezing protection.
  • Fire-proof electric box.
  • Dehumidifying, timer, sleep mode, auto restart, self-diagnosis, automatic operation, LED display, wide swing.
  • Temperature sensor protection.







Specificații

  • Power supply 220-240/50/1 V/Hz/Ph
  • Refrigerant R410A
  • BTU cooling 12000 BTU
  • BTU heating - BTU
  • Cooling capacity 3,52 kW
  • Heating capacity - kW
  • Power consumption C 1,34 kW
  • Power consumption H - kW
  • SEER/SCOP -/- W/W
  • EER/COP 2,61/2,85 W/W
  • Energy class C A
  • Energy class H
  • Rated current C/H 6,0/- A/A
  • Air flow volume (M) 330 m³/h
  • Indoor unit (IDU)
  • Sound pressure level IDU (M) 51 db(A)
  • Sound power level IDU (M) 64 db(A)
  • Net dimensions IDU (WxDxH) 390 x 405 x 820 mm
  • Net weight IDU 39 kg
  • Outdoor unit (ODU)
  • Sound pressure level ODU (M) - dB(A)
  • Sound power level OU (M) - dB(A)
  • Compressor type Rotativ (rotary)
  • Net dimensions ODU (WxDxH) - mm
  • Net weight ODU - kg
  • Piping connection liquid - mm
  • Piping connection gas - mm
  • Max. distance lenght - m
  • Max. distance height - m
  • Refrigerant charge 0,81 kg
  • Operation ambient temp. range C - → - °C
  • Operation ambient temp. range H - → - °C
  • Control Remote

Tabel comparativ

Portable AC units
Modele GPC09AK-K6NNA1AGPC10AN-K5NNA1AGPC12AL-K3NNA2A
Power supply (V/Hz/Ph)220-240/50/1220-240/50/1220-240/50/1
BTU cooling (BTU)90001000012000
BTU heating (BTU)---
Cooling capacity (kW)2,642,903,52
Heating capacity (kW)---
SEER/SCOP (W/W)-/--/--/-
EER/COP (W/W)2,62/-3,10/-2,61/2,85
Energy class CAAA
Energy class H
Air flow volume (M) (m³/h)300330330
Indoor unit (IDU)
Sound pressure level IDU (M) (db(A))495151
Sound power level IDU (M) (db(A))636364
Net dimensions IDU (WxDxH) (mm)315 x 395 x 770405 × 385 × 835390 x 405 x 820
Net weight IDU (kg)3835,539
Outdoor unit (ODU)
Sound pressure level ODU (M) (dB(A))---
Sound power level OU (M) (dB(A))---
Net dimensions ODU (WxDxH) (mm)---
Net weight ODU (kg)---
Piping connection liquid (mm)---
Piping connection gas (mm)---
Max. distance lenght (m)---
Max. distance height (m)---
Refrigerant charge (kg)~ 0,7~ 0,70,81
Operation ambient temp. range C (°C)- → -- → -- → -
Operation ambient temp. range H (°C)- → -- → -- → -
ControlRemoteRemoteRemote
