| AC duct cu presiune statica joasa | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| Modele | GMV-ND22PLS/C-T (7500 BTU) | GMV-ND28PLS/C-T (9000 BTU) | GMV-ND36PLS/C-T (12000 BTU) | GMV-ND45PLS/C-T (16000 BTU) | GMV-ND56PLS/C-T (20000 BTU) | GMV-ND71PLS/C-T (24000 BTU) | GMV-ND90PLS/C-T (32000 BTU) | GMV-ND112PLS/C-T (38000 BTU) | GMV-ND140PLS/C-T (48000 BTU) | |
| Alimentare electrică (V/Hz/Ph) | 220-240/50/1 | 220-240/50/1 | 220-240/50/1 | 220-240/50/1 | 220-240/50/1 | 220-240/50/1 | 220-240/50/1 | 220-240/50/1 | 220-240/50/1 | |
| BTU răcire (BTU) | 7500 | 9500 | 12000 | 15500 | 19000 | 24000 | 31000 | 38000 | 48000 | |
| BTU încălzire (BTU) | 8500 | 11000 | 13500 | 17000 | 21500 | 27000 | 34000 | 42500 | 54500 | |
| Capacitate de răcire (kW) | 2.2 | 2.8 | 3.6 | 4.5 | 5.6 | 7.1 | 9.0 | 11.2 | 14.0 | |
| Capacitate de încălzire (kW) | 2.5 | 3.2 | 4.0 | 5.0 | 6.3 | 8.0 | 10.0 | 12.5 | 16.0 | |
| Debit aer (mediu) (m³/h) | 350 | 350 | 400 | 550 | 700 | 850 | 1250 | 1500 | 1700 | |
| Presiune sonoră UI (niv. mediu) (db(A)) | 25 | 25 | 27 | 29 | 31 | 32 | 36 | 36 | 40 | |
| Racorduri lichid (mm) | 6.35 | 6.35 | 6.35 | 6.35 | 9.52 | 9.52 | 9.52 | 9.52 | 9.52 | |
| Racorduri gaz (mm) | 9.52 | 9.52 | 12.7 | 12.7 | 15.9 | 15.9 | 15.9 | 15.9 | 15.9 | |
| Dimensiuni (W x D x H) (mm) | 710 x 462 x 200 | 710 x 462 x 200 | 710 x 462 x 200 | 1010 x 462 x 200 | 1010 x 462 x 200 | 1310 x 462 x 200 | 1340 x 655 x 260 | 1340 x 655 x 260 | 1340 x 655 x 260 | |
| Presiune statică externă (Pa) | 15-30 | 15-30 | 15-30 | 15-30 | 15-30 | 15-50 | 15-80 | 15-80 | 15-80 | |
