| Power supply (V/Hz/Ph) | 380-400/50/3 | 380-400/50/3 |
| Refrigerant | R410A | R410A |
| BTU cooling (BTU) | 54600 | 61500 |
| BTU heating (BTU) | 48000 | 55000 |
| Cooling capacity (kW) | 16,0 | 18,0 |
| Heating capacity (kW) | 14,0 | 16,0 |
| Power consumption C (kW) | 4,4 | 5,0 |
| Power consumption H (kW) | 4,25 | 4,7 |
| SEER/SCOP (W/W) | - | - |
| EER/COP (W/W) | 2,9*3,2 | 2,8/3,5 |
| Piping connection liquid (mm) | 9,52 | 9,52 |
| Piping connection gas (mm) | 15,9 | 19,05 |
| Operation ambient temp. range C (°C) | +18 → +48 | +18 → +48 |
| Operation ambient temp. range H (°C) | -10 → +24 | -10 → +24 |
| Sound pressure level (M) (dB (A)) | 58 | 58 |
| Net dimensions (WxDxH) (mm) | 900 x 340 x 1345 | 900 x 340 x 1345 |
| Net weight (kg) | 116 | 116 |
| Sound power level (M) (dB (A)) | - | - |
| Air flow volume (m³/h) | 7000 | 7000 |
| Max. distance lenght ODU-IDU/total lenght (m) | 55/80 | 55/90 |
