Monoblock Rivacold BEWT352LA70P12 (LBP, 2161 W) - 380 V

Agregat monobloc Rivacold BEWT352LA70P12 (LBP, 2161W)Agregat frigorific monobloc Rivacold W35Agregat monobloc Rivacold BEWT352LA70P12 (LBP, 2161 W)Agregat frigorific carcasat monofazic Rivacold BEWT352LA70P12
nou
qr Ai observat o eroare?

COD PRODUS

Solicită ofertă PDF

Rivacold monobloc refrigeration unit for freezing, wall-mounted plug-in type, 2 x 38 cm³, 1802 W, R290, 380V

  • Rivacold BEWT352LA70P12 3-phase enclosed refrigeration unit for vertical plug-in mounting.
  • Monoblock unit with cooling capacity of 2161 W at -25ºC (Ta 32ºC) and 1871 W at -25ºC (Ta 43ºC).
  • Applications: freezing (negative temperatures - LBP).
  • Monoblock unit refrigerant: R290 (propane).
  • Compact type unit intended for modular cold rooms, mobile cold rooms and cooled spaces designed for possible relocation/relocation.
  • 2 in 1 unit with 2 x 38 cm³ 3-phase hermetic compressor and 1 350 mm fan at the evaporator.
  • BEST BE W35 range cooling unit air flow: 2740 m³/h.
  • Air flow length: 8 m.
  • Weight of cooling unit BEWT352LA70P12: 114 kg.

Specificații

  • Power supply 380-400/50/3 V/Hz/Ph
  • Application LBP
  • Refrigerant R290
  • Weight 110 kg
  • Mounting vertical, pe perete (vertically, on the wall)
  • Unit type compact plug-in
  • Displacement 2 x 38 cm³
  • Power input 2.3 kW
  • Fan no. 1 + 1
  • Dimension of fan 1 x 350 mm (condens.), 1 x 350 mm (cooler) n° x Ø
  • Fan's air flow 2740 m³/h
  • Air throw 8 m
  • Cooling capacity [W] / Evapor. temp. [°C] (ambient. temp. of 32°C)
    • -25°C : 2161 W
    • -20°C : 2580 W
    • -15°C : 3030 W
    • -5°C : - W
    • 0°C : - W
    • 5°C : - W

Tabel comparativ

Wall-mounted monoblocks Rivacold
Modele Power supply (V/Hz/Ph)ApplicationMountingUnit typeDisplacement (cm³)Air throw (m)Cooling capacity [W] / Evapor. temp. [°C] (ambient. temp. of 32°C) (W)
-25°C-20°C-15°C-5°C0°C5°C
BEWS251LA10P11220-240/50/1LBPvertical, pe perete (vertically, on the wall) compact tip șa (saddle)18.76.5554663782---
BEWT251LA10P11220-240/50/1LBPvertical, pe perete (vertically, on the wall)compact plug-in18.76.5554663782---
BEWS251LA20P11220-240/50/1LBPvertical, pe perete (vertically, on the wall) compact tip șa (saddle)27.86.57709191082---
BEWT251LA20P11220-240/50/1LBPvertical, pe perete (vertically, on the wall)compact plug-in27.86.57709191082---
BEWS301LA30P11220-240/50/1LBPvertical, pe perete (vertically, on the wall) compact tip șa (saddle)27.86.589210691263---
BEWT301LA30P11220-240/50/1LBPvertical, pe perete (vertically, on the wall)compact plug-in27.86.589210691263---
BEWS301LA40P12380-400/50/3LBPvertical, pe perete (vertically, on the wall) compact tip șa (saddle)38.06.5106712741497---
BEWT301LA40P12380-400/50/3LBPvertical, pe perete (vertically, on the wall)compact plug-in38.06.5106712741497---
BEWS302LA50P11220-240/50/1LBPvertical, pe perete (vertically, on the wall) compact tip șa (saddle)2 x 22.46.5128315391824---
BEWT302LA50P11220-240/50/1LBPvertical, pe perete (vertically, on the wall)compact plug-in2 x 22.46.5128315391824---
BEWS352LA60P11220-240/50/1LBPvertical, pe perete (vertically, on the wall) compact tip șa (saddle)2 x 27.88180221612553---
BEWT352LA60P11220-240/50/1LBPvertical, pe perete (vertically, on the wall)compact plug-in2 x 27.88180221612553---
BEWS352LA70P12380-400/50/3LBPvertical, pe perete (vertically, on the wall) compact tip șa (saddle)2 x 388216125803030---
BEWT352LA70P12380-400/50/3LBPvertical, pe perete (vertically, on the wall)compact plug-in2 x 388216125803030---
BEWS251MA10P11220-240/50/1MBP
HBP		vertical, pe perete (vertically, on the wall) compact tip șa (saddle)12.16.5---8129381073
BEWT251MA10P11220-240/50/1MBP
HBP		vertical, pe perete (vertically, on the wall)compact plug-in12.16.5---8129381073
BEWS251MA20P11220-240/50/1MBP
HBP		vertical, pe perete (vertically, on the wall) compact tip șa (saddle)16.86.5---109112561434
BEWT251MA20P11220-240/50/1MBP
HBP		vertical, pe perete (vertically, on the wall)compact plug-in16.86.5---109112561434
BEWS301MA30P11220-240/50/1MBP
HBP		vertical, pe perete (vertically, on the wall) compact tip șa (saddle)22.46.5---139016071840
BEWT301MA30P11220-240/50/1MBP
HBP		vertical, pe perete (vertically, on the wall)compact plug-in22.46.5---139016071840
BEWS301MA40P11220-240/50/1MBP
HBP		vertical, pe perete (vertically, on the wall) compact tip șa (saddle)27.86.5---175920232304
BEWT301MA40P11220-240/50/1MBP
HBP		vertical, pe perete (vertically, on the wall)compact plug-in27.86.5---175920232304
BEWS302MA50P11220-240/50/1MBP
HBP		vertical, pe perete (vertically, on the wall) compact tip șa (saddle)2 x 16.86.5---218925212876
BEWT302MA50P11220-240/50/1MBP
HBP		vertical, pe perete (vertically, on the wall)compact plug-in2 x 16.86.5---218925212876
BEWS352MA60P11220-240/50/1MBP
HBP		vertical, pe perete (vertically, on the wall) compact tip șa (saddle)2 x 20.48.0---263030663537
BEWT352MA60P11220-240/50/1MBP
HBP		vertical, pe perete (vertically, on the wall)compact plug-in2 x 20.48.0---263030663537
BEWS352MA70P11220-240/50/1MBP
HBP		vertical, pe perete (vertically, on the wall) compact tip șa (saddle)2 x 22.48.0---280832453716
BEWT352MA70P11220-240/50/1MBP
HBP		vertical, pe perete (vertically, on the wall)compact plug-in2 x 22.48.0---280832453716
BEWS352MA80P11220-240/50/1MBP
HBP		vertical, pe perete (vertically, on the wall) compact tip șa (saddle)2 x 27.88.0---340539044435
BEWT352MA80P11220-240/50/1MBP
HBP		vertical, pe perete (vertically, on the wall)compact plug-in2 x 27.88.0---340539044435
