Air conditioning Toshiba Daisekai 10 White 13000 BTU (R32)

Offer request PDF

Toshiba professional wall-mounted air conditioner, 3.5/4.0 kW, class A+++, R32, active WiFi, ionizer filter, ECO panel

Toshiba Daisekai 10 White 13000 BTU - inverter air conditioner A+++/A+++.
Ecological panel with contemporary appearance made of 43% recycled materials.
The highest energy efficiency on the market!
Perfect fit for users with respiratory sensitivities: the Ultra Pure filter captures 94% of 2.5 PM particles.
Neutralizes odors generated by cigarette smoke, cooking or other unpleasant odors.
Split air conditioner RAS-B13S4KVPG-E + RAS-13S4AVPG-E with Smart Sensing and Motion Tracking functions, delivering the freshest conditioned air right to where users are - see video.
Toshiba Daisekai White with active WiFi control.
Remarkable silence of at least 20 db(A).
Japanese inverter technology with great reliability thanks to the DC Rotary double compressor that minimizes fluctuations to ensure a constant temperature.

Refrigerant R32
Power supply 220-240/50/1 V/Hz/Ph
BTU cooling 12000 BTU
BTU heating 13600 BTU
Cooling capacity 3.5 kW
Heating capacity 4.0 kW
Energy class C A+++
Energy class H A+++
EER/COP 4.38/5.00 W/W
SEER/SCOP 9.7/5.2 W/W
Indoor unit (IDU) ▼
Air flow volume 750 m³/h
Sound pressure level
- Răcire (cooling) : 41/20 db(A)
- Încălzire (heating) : 42/20 db(A)
Sound power level max.
- Răcire (cooling) : 54 db(A)
- Încălzire (heating) : 55 db(A)
Net dimensions IDU (WxDxH) 930 x 255 x 293 mm
Net weight IDU 14 kg
Control Remote, WI-FI
Outdoor unit (ODU) ▼
Sound pressure level ODU (max.) 45 dB(A)
Sound power level max. (ODU)
- Răcire (cooling) : 58 db(A)
- Încălzire (heating) : 59 db(A)
Compressor type Inverter rotary
Net dimensions ODU (WxDxH) 630 x 300 x 800 mm
Net weight ODU 38 kg
Piping connection liquid 6 mm
Piping connection gas 9.52 mm
Max. distance lenght 25 m
Max. distance height 15 m
Refrigerant charge 0.96 kg
Operation ambient temp. range C -15 → 46 °C
Operation ambient temp. range H -20 → 24 °C

Toshiba Daisekai 10 White (R32)
Modele		Daisekai 10 White 10000 BTU	Daisekai 10 White 13000 BTU	Daisekai 10 White 18000 BTU
Refrigerant		R32	R32	R32
Power supply (V/Hz/Ph)		220-240/50/1	220-240/50/1	220-240/50/1
BTU cooling (BTU)		8500	12000	17000
BTU heating (BTU)		11000	13600	20500
Cooling capacity (kW)		2.5	3.5	5.0
Heating capacity (kW)		3.2	4.0	6.0
Energy class C		A+++	A+++	A+++
Energy class H		A+++	A+++	A+++
Indoor unit (IDU)		▼	▼	▼
Air flow volume (m³/h)		700	750	800
Sound pressure level (db(A))	Răcire (cooling)	40/19	41/20	44/22
Sound pressure level (db(A))	Încălzire (heating)	41/19	42/20	45/22
Sound power level max. (db(A))	Răcire (cooling)	53	54	57
Sound power level max. (db(A))	Încălzire (heating)	54	55	58
Net dimensions IDU (WxDxH) (mm)		930 x 255 x 293	930 x 255 x 293	930 x 255 x 293
Net weight IDU (kg)		14	14	14
Control		Remote WI-FI	Remote WI-FI	Remote WI-FI
Outdoor unit (ODU)		▼	▼	▼
Sound pressure level ODU (max.) (dB(A))		44	45	47
Sound power level max. (ODU) (db(A))	Răcire (cooling)	57	58	60
Sound power level max. (ODU) (db(A))	Încălzire (heating)	54	59	55
Compressor type		Inverter rotary	Inverter rotary	Inverter rotary
Net dimensions ODU (WxDxH) (mm)		630 x 300 x 800	630 x 300 x 800	630 x 300 x 800
Net weight ODU (kg)		38	38	38
Piping connection liquid (mm)		6	6	6
Piping connection gas (mm)		9.52	9.52	12
Max. distance lenght (m)		25	25	25
Max. distance height (m)		15	15	15
Refrigerant charge (kg)		0.96	0.96	0.96
Operation ambient temp. range C (°C)		-15 → 46	-15 → 46	-15 → 46
Operation ambient temp. range H (°C)		-20 → 24	-20 → 24	-20 → 24
