| Console type units (R32) | ||||
|---|---|---|---|---|
| Modele | GEH09AA-K6DNA1F/I+O | GEH12AA-K6DNA1A/I+O | GEH18AA-K6DNA1F/I+O | |
| Power supply (V/Hz/Ph) | 220-240/50/1 | 220-240/50/1 | 220-240/50/1 | |
| BTU cooling (BTU) | 9200 | 12000 | 17700 | |
| BTU heating (BTU) | 10000 | 13000 | 18100 | |
| Cooling capacity (kW) | 2,7 | 3,5 | 5,2 | |
| Heating capacity (kW) | 2,9 | 3,80 | 5,3 | |
| SEER/SCOP (W/W) | 7,2/4,0 | 7,0/4,1 | 6,6/- | |
| EER/COP (W/W) | 3,75/3,97 | 3,52/3,96 | 3,4/3,5 | |
| Energy class C | A++ | A++ | A++ | |
| Energy class H | A+ | A+ | A+ | |
| Air flow volume (M) (m³/h) | 370 | 440 | 520 | |
| Indoor unit (IDU) | ||||
| Sound pressure level IDU (M) (db(A)) | 31 | 36 | 40 | |
| Sound power level IDU (M) (db(A)) | 44 | 46 | 50 | |
| Net dimensions IDU (WxDxH) (mm) | 700 x 215 x 600 | 700 x 215 x 600 | 700 x 215 x 600 | |
| Net weight IDU (kg) | 15,5 | 15,5 | 15,5 | |
| Outdoor unit (ODU) | ||||
| Sound pressure level ODU (M) (dB(A)) | 49 | 52 | 57 | |
| Sound power level OU (M) (dB(A)) | 60 | 62 | 65 | |
| Net dimensions ODU (WxDxH) (mm) | 782 x 320 x 540 | 848 x 320 x 596 | 965 x 396 x 700 | |
| Net weight ODU (kg) | 27,5 | 30,5 | 46 | |
| Piping connection liquid (mm) | 6 | 6 | 6 | |
| Piping connection gas (mm) | 9,52 | 9,52 | 12 | |
| Max. distance lenght (m) | 20 | 20 | 25 | |
| Max. distance height (m) | 10 | 10 | 10 | |
| Refrigerant charge (kg) | 0,55 | 0,75 | 0,95 | |
| Operation ambient temp. range C (°C) | -15 → +43 | -15 → +43 | -15 → +43 | |
| Operation ambient temp. range H (°C) | -20 → +24 | -20 → +24 | -20 → +24 | |
| Control | Remote WI-FI | Remote WI-FI | Remote WI-FI | |
