Danfoss DML 414 filter drier
Solder type dehydrator filter DML414S, internal manufacturer code 023Z4594 (inch), 023Z4593 (mm)
- Disposal filter that protects the refrigeration / air conditioning system from: moisture, acid and unwanted solid particles.
- Danfoss filter DML 414S 023Z4594 with equal weldable connection 1/2" ODF and DML 414S 023Z4593 with equal weldable ODF connection 12 mm.
- High drying capacity minimizing the risk of acid formation (hydrolysis).
- Helps keep the circuit clean, reducing operating costs. Recommended for use with R134a, R404A, R32, R410A, R407C, R23, R600, R600a, R1234yf, R1234ze, R407F, R290, R452A, R444B, R449A, R448A and R450A (POE / PAG functional circuits).
- Liquid capacity: 31.6 kW (R134a); 17.5 kW (R404a, R507); 35.1 kW (R22, R407C, R410A).
- Dehydration capacity: 80.2 kg (R134a); 130 kg (R507, R404A); 80.2 kg (R22, R407C, R410A).
- Basic composition 100% molecular sieve.
- Nominal size 41 cubic inches.
- Original Danfoss filter, made in Mexico.
- Equal connection (mm) 12 mm
- Equal connections (") 1/2 "
- Filter type sudabil (solder)
- Inlet x out. connections
- inch : 1/2 x 1/2
- mm : 12 x 12
- Filter dimensions
- lung. cu conexiuni (length with connect.) : mm
- lung. corp filtru (filter body length) : mm
- diam. transversal (diameter) : mm
Danfoss DML 414 filter drier
