Danfoss pressure regulator KVP12 - 034L0028

Regulator de presiune Danfoss pentru vaporizatorRegulator de presiune Danfoss pentru vaporizatorRegulator de presiune Danfoss pentru vaporizatorRegulator de presiune Danfoss pentru vaporizator
qr Ai observat o eroare?

COD DTN

  • 207.18.1008

COD PRODUS

Solicită ofertă PDF

Pressure regulator for evaporators, KVP range, solder connection

  • Is mounted in the suction line after the evaporator.
  • It maintains a constant evaporating pressure and thereby a constant surface temperature on the evaporator.
  • Protect against an evaporating pressure that is too low.

Specificații

  • Connection sudabilă (solder)
  • Inlet x out. connections
    • inch : -
    • mm : 12 x 12
  • Working domain 0 → 5,5 bar

Tabel comparativ

Pressure regulators for evaporators
Modele ConnectionInlet x out. connectionsWorking domain (bar)
inchmm
KVP12 - 034L0023sudabilă (solder)1/2 x 1/2-0 → 5,5
KVP12 - 034L0021filetată (flare)1/2 x 1/2-0 → 5,5
KVP12 - 034L0028sudabilă (solder)-12 x 120 → 5,5
KVP12 - 034L0022filetată (flare)5/8 x 5/8-0 → 5,5
KVP15 - 034L0029sudabilă (solder)-16 x 160 → 5,5
KVP22 - 034L0025sudabilă (solder)-22 x 220 → 5,5
KVP28 - 034L0026sudabilă (solder)1-1/8 x 1-1/8-0 → 5,5
KVP28 - 034L0031sudabilă (solder)-28 x 280 → 5,5
KVP35 - 034L0032sudabilă (solder)-35 x 350 → 5,5
