| Power supply (V/Hz/Ph) | 220-240/50/1 | 220-240/50/1 | 220-240/50/1 | 220-240/50/1 | 220-240/50/1 |
| Refrigerant | R410A | R410A | R410A | R410A | R410A |
| BTU cooling (BTU) | 18400 | 29000 | 31700 | 41000 | 44400 |
| BTU heating (BTU) | 17800 | 24200 | 27300 | 36000 | 41300 |
| Cooling capacity (kW) | 5,4 | 8,5 | 9,3 | 12,0 | 13,0 |
| Heating capacity (kW) | 5,2 | 7,1 | 8,0 | 10,5 | 12,1 |
| Power consumption C (kW) | 1,4 | 2,1 | 2,5 | 3,5 | 3,5 |
| Power consumption H (kW) | 1,4 | 2,2 | 2,4 | 3,75 | 3,5 |
| SEER/SCOP (W/W) | 6,1/4,0 | 6,1/4,0 | 6,1/4,0 | 5,5/3,8 | - |
| EER/COP (W/W) | - | - | - | - | - |
| Piping connection liquid (mm) | 6 | 6 | 6 | 3 x 6,35; 1 x 9,52 | 4 x 6,35; 1 x 9,52 |
| Piping connection gas (mm) | 9,52 | 9,52 | 9,52 | 2 x 9,52; 1 x 12,7; 1 x 15,9 | 2 x 9,52; 2 x 12,7; 1 x 15,9 |
| Operation ambient temp. range C (°C) | -15 → +43 | -15 → +43 | -15 → +43 | -15 → +48 | -15 → +48 |
| Operation ambient temp. range H (°C) | -20 → +24 | -20 → +24 | -20 → +24 | -15 → +27 | -15 → +27 |
| Sound pressure level (M) (dB (A)) | 55 | 56 | 56 | 54 | 54 |
| Net dimensions (WxDxH) (mm) | 963 x 396 x 700 | 10001 X 427 x 790 | 1001 x 427 x 790 | 1015 X 440 X 1103 | 1015 x 440 x 1103 |
| Net weight (kg) | 51 | 68 | 69 | 94 | 102 |
| Sound power level (M) (dB (A)) | 62 | 65 | 65 | 64 | 64 |
| Air flow volume (m³/h) | 3200 | 4000 | 4000 | 5200 | 5500 |
| Max. distance lenght ODU-IDU/total lenght (m) | 10/20 | 20/60 | 20/70 | 20/70 | 25/80 |
