Wall-mounted indoor unit AUX C-Smart CCB 12000 BTU for multisplit

Wall-mounted indoor unit AUX C-Smart CCB 12000 BT

nou

Ai observat o eroare?

COD PRODUS

AUX C-Smart CCB 12000 BTU Multisplit (R32)

C-SMART CCB PANEL AMWM-H12/4R3(CCB)

Solicită ofertă PDF

Inverter AUX air conditioner 3.52 kW for multisplit, WiFi, black panel, air flow through microholes

AUX C-Smart CCB Black AMWM-H12/4R3(CCB) split air conditioner 12000 BTU for multisplit AUX.
Wall AC unit for multisplit air conditioning for home and office.
Addition for double split air conditioner or with more splitters (AUX Free Match).
The outdoor unit and the optional AUX wall controller are purchased separately.
The AUX C-Smart CCB model with black panel includes Micro Vent technology against disturbing air flow.
The 3206 micro-holes in front of the air outlet slot eliminate strong air currents, ensuring soft air conditioning.
The device can also be set to direct air conditioning and Turbo function.
Wall air conditioner for multisplit, 3.52-3.81 kW, with premium design.
Glossy black panel - ideal for contemporary furnishings!
Multisplit air conditioner with IR and remote control (WiFi).

Specificații

BTU cooling 12000 BTU
BTU heating 13000 BTU
Cooling capacity 3.52 kW
Heating capacity 3.81 kW
Power supply 220-240/50/1 V/Hz/Ph
Power consumption C 0.87 kW
Power consumption H 1.06 kW
SEER/SCOP 8.5/4.6 W/W
EER/COP 4.02/3.96 W/W
Energy class C A+++
Energy class H A++
Indoor unit (IDU) ▼
Sound pressure level IDU (M) 31 db(A)
Sound power level IDU (M) 56 db(A)
Net dimensions IDU (WxDxH) 774 x 202 x 298 mm mm
Net weight IDU 7.5 kg
Outdoor unit (ODU) ▼
Sound pressure level ODU (M) - dB(A)
Sound power level OU (M) - dB(A)
Net dimensions ODU (WxDxH) - mm
Net weight ODU - kg
Piping connection liquid - mm
Piping connection gas - mm
Max. distance lenght - m
Max. distance height - m
Refrigerant charge - kg
Operation ambient temp. range C - → - °C
Operation ambient temp. range H - → - °C
Control Remote, WI-FI, Wired (optional)

Tabel comparativ

AUX wall-mounted indoor units
Modele	AUX J-Smart 9000 BTU Multisplit (R32)	AUX J-Smart 12000 BTU Multisplit (R32)	AUX J-Smart 18000 BTU Multisplit (R32)	AUX C-Smart 9000 BTU Multisplit (R32)	AUX C-Smart 12000 BTU Multisplit (R32)	AUX C-Smart 18000 BTU Multisplit (R32)	AUX C-Smart CCB 9000 BTU Multisplit (R32)	AUX C-Smart CCB 12000 BTU Multisplit (R32)	AUX C-Smart CCB 18000 BTU Multisplit (R32)	AUX C-Smart CCB 24000 BTU Multispl
BTU cooling (BTU)	9200	12000	18000	9200	12000	16000	9000	12000	18000
BTU heating (BTU)	10200	13000	19100	11000	14000	17100	10000	13000	18400
Cooling capacity (kW)	2.7	3.5	5.3	2.7	3.5	4.7	2.64	3.52	5.27
Heating capacity (kW)	3.0	3.8	5.6	3.3	4.2	5.0	2.93	3.81	5.38
Power supply (V/Hz/Ph)	220-240/50/1	220-240/50/1	220-240/50/1	220-240/50/1	220-240/50/1	220-240/50/1	220-240/50/1	220-240/50/1	220-240/50/1
Power consumption C (kW)	0.80	1.18	1.58	0.64	0.87	1.43	0.64	0.87	1.43
Power consumption H (kW)	0.85	1.10	1.55	0.72	1.06	1.33	0.72	1.06	1.33
SEER/SCOP (W/W)	8.5/4.6	8.5/4.6	8.8/4.6	8.5/4.6	8.5/4.6	8.8/4.6	8.5/4.6	8.5/4.6	8.8/4.6
EER/COP (W/W)	4.3/4.72	4.0/3.96	3.27/3.61	4.3/4.72	4.02/3.96	3.27/3.61	4.3/4.72	4.02/3.96	3.27/3.61
Energy class C	A++	A++	A++	A+++	A+++	A+++	A+++	A+++	A+++
Energy class H	A+++	A+++	A+++	A++	A++	A++	A++	A++	A++
Indoor unit (IDU)	▼	▼	▼	▼	▼	▼	▼	▼	▼
Sound pressure level IDU (M) (db(A))	32	32	35	27	31	35	27	31	35
Sound power level IDU (M) (db(A))	40	40	41	38	56	56	38	56	56
Net dimensions IDU (WxDxH) (mm)	792 x 201 x 292	792 x 201 x 292	940 x 224 x 316	774 x 202 x 299 mm	834 x 202 x 299 mm	1145 x 230 x 331 mm	774 x 202 x 298 mm	774 x 202 x 298 mm	1002 x 223 x 318 mm
Net weight IDU (kg)	8.5	8.5	11.5	8.0	8.5	13.0	7.0	7.5	11
Outdoor unit (ODU)	▼	▼	▼	▼	▼	▼	▼	▼	▼
Sound pressure level ODU (M) (dB(A))	-	-	-	-	-	-	-	-	-
Sound power level OU (M) (dB(A))	-	-	-	-	-	-	-	-	-
Net dimensions ODU (WxDxH) (mm)	-	-	-	-	-	-	-	-	-
Net weight ODU (kg)	-	-	-	-	-	-	-	-	-
Piping connection liquid (mm)	-	-	-	-	-	-	-	-	-
Piping connection gas (mm)	-	-	-	-	-	-	-	-	-
Max. distance lenght (m)	-	-	-	-	-	-	-	-	-
Max. distance height (m)	-	-	-	-	-	-	-	-	-
Refrigerant charge (kg)	-	-	-	-	-	-	-	-	-
Operation ambient temp. range C (°C)	- → -	- → -	- → -	- → -	- → -	- → -	- → -	- → -	- → -	→
Operation ambient temp. range H (°C)	- → -	- → -	- → -	- → -	- → -	- → -	- → -	- → -	- → -	→
Control	Remote WI-FI Wired (optional)	Remote WI-FI Wired (optional)	Remote WI-FI Wired (optional)	Remote WI-FI Wired (optional)	Remote WI-FI Wired (optional)	Remote WI-FI Wired (optional)	Remote WI-FI Wired (optional)	Remote WI-FI Wired (optional)	Remote WI-FI Wired (optional)
