Alco filter drier FDB-162 (SAE, 1/4")

Filtru deshidrator Alco FDB-162 (filetat, 1/4

Ai observat o eroare?

COD PRODUS

FDB-162 1/4"

FILTER DRIER FDB 162 ALCO 059317

Solicită ofertă PDF

Flared filter drier FDB-162 059317 (SAE), equal connections of 1/4" (6 mm)

AC filter drier FDB 059317 with compact structure and hermetic closure.
Filter length with connections: ∼160 mm.
Filter drier FDB-162 with 12 mm (1/2") flared connections.
Optimized capacity for absorbing acidity and moisture.
FDB 162 for temperature range from -40°C to +65°C.
Maximum operating pressure: 45 bar.
Anti-corrosion paint resistant to outdoor use.
Contributes to keeping the circuit clean, resulting in low operating costs.

Specificații

Equal connection (mm) mm
Equal connections (") 1/4 "
Filter type filetat (flare)
Inlet x out. connections
- inch : 1/4 x 1/4
- mm :
Filter dimensions
- lung. cu conexiuni (length with connect.) : 160 mm
- lung. corp filtru (filter body length) : 122 mm
- diam. transversal (diameter) : 67 mm

Tabel comparativ

Alco filter driers
Modele	Equal connection (mm) (mm)	Equal connections (") (")	Filter type	Inlet x out. connections		Filter dimensions (mm)
Modele	Equal connection (mm) (mm)	Equal connections (") (")	Filter type	inch	mm	lung. cu conexiuni (length with connect.)	lung. corp filtru (filter body length)	diam. transversal (diameter)
FDB-032S 1/4"		1/4	sudabil (solder)	1/4 x 1/4		100	65	43
FDB-032 6 mm	6		filetat (flare)		6 x 6	115	65	44
FDB-052S 1/4"	6	1/4	sudabil (solder)	1/4 x 1/4	6	110	77	67
FDB-052 6 mm	6		filetat (flare)		6 x 6	110	77	67
FDB-053S 3/8"		3/8	sudabil (solder)	3/8 x 3/8		123	77	67
FDB-053 10 mm	10		filetat (flare)		10 x 10	130	77	67
FDB-082S 1/4"		1/4	sudabil (solder)	1/4 x 1/4		145	100	67
FDB-082 6 mm	6		filetat (flare)		6 x 6	130	98	67
FDB-083S 3/8"		3/8	sudabil (solder)	3/8 x 3/8		153	100	67
FDB-083 10 mm	10		filetat (flare)		10 x 10	140	98	67
FDB-084S 1/2"		1/2	sudabil (solder)	1/2 x 1/2		160	100	67
FDB-084 12 mm	12		filetat (flare)		12 x 12	140	98	67
FDB-162 1/4"		1/4	filetat (flare)	1/4 x 1/4		160	122	67
FDB-163S 3/8"		3/8	sudabil (solder)	3/8 x 3/8		176	123	67
FDB-163 10 mm	10		filetat (flare)		10 x 10	160	122	67
FDB-164S 1/2"		1/2	sudabil (solder)	1/2 x 1/2		185	123	67
FDB-164 12 mm	12		filetat (flare)		12 x 12	185	123	67
FDB-165S 5/8"		5/8	sudabil (solder)	5/8 x 5/8		195	122	67
FDB-165 16 mm	16		filetat (flare)		16 x 16	190	122	67
FDB-303 3/8"		3/8	filetat (flare)	3/8 x 3/8		245	190	80
FDB-304S 1/2"		1/2	sudabil (solder)	1/2 x 1/2		226	190	80
FDB-304 12 mm	12		filetat (flare)		12 x 12	251	190	80
FDB-305S 5/8"		5/8	sudabil (solder)	5/8 x 5/8		260	190	80
FDB-305 16 mm	16		filetat (flare)		16 x 16	252	190	80
FDB-307S 7/8"		7/8	sudabil (solder)	7/8 x 7/8		260	190	80
FDB-415 16 mm	16		filetat (flare)		16 x 16	265	190	80
FDB-417S 7/8"		7/8	sudabil (solder)	7/8 x 7/8		255	195	92
