| U-Crown (R32) | |||
|---|---|---|---|
| Modele | GWH12UB-K6DNA4A/I+O | GWH18UC-K6DNA4F/I+O | |
| Power supply (V/Hz/Ph) | 220-240/50/1 | 220-240/50/1 | |
| BTU cooling (BTU) | 12500 | 18000 | |
| BTU heating (BTU) | 12000 | 18000 | |
| Cooling capacity (kW) | 3,5 | 5,27 | |
| Heating capacity (kW) | 3,6 | 5,27 | |
| SEER/SCOP (W/W) | 7,0/4,6 | 6,1/4,0 | |
| EER/COP (W/W) | 3,8/3,71 | 3,3/3,72 | |
| Energy class C | A++ | A+ | |
| Energy class H | A++ | A++ | |
| Air flow volume (M) (m³/h) | 420 | 600 | |
| Indoor unit (IDU) | |||
| Sound pressure level IDU (M) (db(A)) | 34 | 40 | |
| Sound power level IDU (M) (db(A)) | 47 | 52 | |
| Net dimensions IDU (WxDxH) (mm) | 860 X 170 X 305 | 960 X 205 X 320 | |
| Net weight IDU (kg) | 12,5 | 14 | |
| Outdoor unit (ODU) | |||
| Sound pressure level ODU (M) (dB(A)) | 50 | 56 | |
| Sound power level OU (M) (dB(A)) | 60 | 62 | |
| Net dimensions ODU (WxDxH) (mm) | 899 X 378 X 596 | 965 X 396 X 700 | |
| Net weight ODU (kg) | 43 | 51 | |
| Piping connection liquid (mm) | 6 | 6 | |
| Piping connection gas (mm) | 12 | 12 | |
| Max. distance lenght (m) | 20 | 25 | |
| Max. distance height (m) | 10 | 10 | |
| Refrigerant charge (kg) | 0.9 | 1.4 | |
| Operation ambient temp. range C (°C) | -18 → +54 | -18 → +54 | |
| Operation ambient temp. range H (°C) | -30 → +24 | -30 → +24 | |
| Control | Remote WI-FI | Remote WI-FI | |
