| Power supply (V/Hz/Ph) | 220-240/50/1 | 220-240/50/1 | 220-240/50/1 | 220-240/50/1 | 220-240/50/1 |
| Refrigerant | R32 | R32 | R32 | R32 | R32 |
| BTU cooling (BTU) | 18500 | 29000 | 32500 | 41000 | 41000 |
| BTU heating (BTU) | 18000 | 24200 | 28000 | 36000 | 41000 |
| Cooling capacity (kW) | 5,4 | 8,5 | 9,5 | 12,0 | 12,0 |
| Heating capacity (kW) | 5,2 | 7,1 | 8,0 | 10,5 | 12,0 |
| Power consumption C (kW) | 1,4 | 1,9 | 2,3 | 3,1 | 3,4 |
| Power consumption H (kW) | 1,3 | 2,2 | 2,6 | 3,2 | 3,5 |
| SEER/SCOP (W/W) | 3,59/4,15 | 3,64/3,86 | 3,48/3,58 | - | - |
| EER/COP (W/W) | - | - | - | - | - |
| Piping connection liquid (mm) | 2 x 6,35 | 3 x 6,35 | 4 x 6,35 | 3 x 6,35; 1 x 9,52 | 4 x 6,35; 1 x 9,52 |
| Piping connection gas (mm) | 2 x 9,52 | 3 x 9,52 | 4 x 9,52 | 2 x 9,52; 1 x 12,7; 1 x 15,9 | 2 x 9,52; 2 x 12,7; 1 x 15,9 |
| Operation ambient temp. range C (°C) | -15 → +43 | -15 → +43 | -15 → +43 | -15 → +43 | -15 → +43 |
| Operation ambient temp. range H (°C) | -20 → +24 | -22 → +24 | -20 → +24 | -20 → +24 | -20 → +24 |
| Sound pressure level (M) (dB (A)) | - | - | - | - | - |
| Net dimensions (WxDxH) (mm) | 899 X 378 X 596 | 1001 x 427 x 790 | 1001 x 427 x 790 | 1087 x 440 x 1103 | 1087 x 440 x 1103 |
| Net weight (kg) | 43 | 68 | 69 | 90 | 90 |
| Sound power level (M) (dB (A)) | - | - | - | - | - |
| Air flow volume (m³/h) | 2600 | 2600 | 2600 | 5500 | 5500 |
| Max. distance lenght ODU-IDU/total lenght (m) | 10/20 | 20/60 | 20/70 | 25/75 | 25/75 |
