| Toshiba Edge White (R32) | ||||||||
|---|---|---|---|---|---|---|---|---|
| Modele | Toshiba Edge White 10000 BTU | Toshiba Edge White 13000 BTU | Toshiba Edge White 16000 BTU | Toshiba Edge White 18000 BTU | Toshiba Edge White 22000 BTU | Toshiba Edge White 24000 BTU | ||
| Refrigerant | R32 | R32 | R32 | R32 | R32 | R32 | ||
| Power supply (V/Hz/Ph) | 220-240/50/1 | 220-240/50/1 | 220-240/50/1 | 220-240/50/1 | 220-240/50/1 | 220-240/50/1 | ||
| BTU cooling (BTU) | 8500 | 12000 | 16000 | 17100 | 21000 | 24000 | ||
| BTU heating (BTU) | 11000 | 14500 | 19000 | 20500 | 24000 | 27500 | ||
| Cooling capacity (kW) | 2.5 | 3.5 | 4.6 | 5.0 | 6.1 | 7.0 | ||
| Heating capacity (kW) | 3.2 | 4.2 | 5.5 | 6.0 | 7.0 | 8.0 | ||
| Energy class C | A+++ | A+++ | A++ | A++ | A++ | A++ | ||
| Energy class H | A+++ | A+++ | A++ | A++ | A++ | A+ | ||
| Air flow volume (m³/h) | 660 | 732 | 750 | 990 | 1032 | 1122 | ||
| Sound pressure level (db(A)) | Răcire (cooling) | 40/19 | 43/19 | 44/21 | 44/26 | 45/27 | 47/28 | |
| Încălzire (heating) | 40/19 | 43/19 | 44/21 | 44/26 | 46/27 | 48/28 | ||
| Net dimensions IDU (WxDxH) (mm) | 800 x 226 x 293 | 800 x 226 x 293 | 800 x 226 x 293 | 1053 x 226 x 320 | 1053 x 245 x 320 | 1053 x 245 x 320 | ||
| Net weight IDU (kg) | 10 | 10 | 10 | 14 | 14 | 14 | ||
| Control | Remote Optional WiFi | Remote Optional WiFi | Remote Optional WiFi | Remote Optional WiFi | Remote Optional WiFi | Remote Optional WiFi | ||
| ODU compatibility | RAS-3M18U2AVG-E | RAS-3M18U2AVG-E | RAS-3M18U2AVG-E | |||||
