Wall-mounted Gree U-Crown 18000 BTU (R410A)

Gree U-Crown multi 3Gree U-Crown multi 2Gree U-Crown Inverter indoor units Gree U-Crown Inverter indoor unit Gree U-Crown Inverter front perspectiveGree U-Crown Inverter perspective
qr Ai observat o eroare?

COD PRODUS

Solicită ofertă PDF

Latter-day design (luxury range), extended ambient temperature range, WI-FI flexible control

  • Smart WI-FI and Cold Plasma filters.
  • Supplying air from wide range of 130° (left-right) and 180° (up-down).
  • Super low noise  -  the noise is lower to 26 db(A).
  • Alluminium cover (for 9000 and 12000 BTU) and special synthetic material for 18000 BTU.
  • In order to combine with Super Free-Match, you need branch-box.

Specificații

  • Power supply 220-240/50/1 V/Hz/Ph
  • Refrigerant R410A
  • BTU cooling 18000 BTU
  • BTU heating 18000 BTU
  • Cooling capacity 5,2 kW
  • Heating capacity 5,2 kW
  • Power consumption C 1,6 kW
  • Power consumption H 1,4 kW
  • SEER/SCOP 6,1/4,0 W/W
  • EER/COP 3,3/3,72 W/W
  • Rated current C/H 7,1/6,2 A/A
  • Air flow volume (M) 600 m³/h
  • Piping connection liquid 6 mm
  • Piping connection gas 12 mm
  • Control Remote, Wired (optional), WI-FI, Centralized (optional)
  • Sound pressure level (M) 36 dB (A)
  • Net dimensions (WxDxH) 960 x 205 x 320 mm
  • Net weight 14 kg
  • Sound power level (M) 48 dB (A)
  • Free-Match compatibility GWHD(36)NK3BO, GWHD(42)NK3AO
  • Super Free-Match compatibility GWHD(56S)NK3CO, GWHD(48S)NM3DO, GWHD(56S)NM3DO

Tabel comparativ

U-Crown (R410A)
Modele GWH09UB-K3DNA4F/IGWH12UB-K3DNA4F/IGWH18UC-K3DNA4F/I
Power supply (V/Hz/Ph)220-240/50/1220-240/50/1220-240/50/1
RefrigerantR410AR410AR410A
BTU cooling (BTU)90001200018000
BTU heating (BTU)102001230018000
Cooling capacity (kW)2,63,55,2
Heating capacity (kW)3,03,65,2
Air flow volume (M) (m³/h)400420600
Piping connection liquid (mm)666
Piping connection gas (mm)121212
ControlRemote
Wired (optional)
WI-FI
Centralized (optional)		Remote
Wired (optional)
WI-FI
Centralized (optional)		Remote
Wired (optional)
WI-FI
Centralized (optional)
Sound pressure level (M) (dB (A))333436
Net dimensions (WxDxH) (mm)860 x 170 x 305860 x 170 x 305960 x 205 x 320
Net weight (kg)12,512,514
Sound power level (M) (dB (A))464748
Free-Match compatibility
Super Free-Match compatibility

Accesorii

Wired controller Gree XK76

Wired controller Gree XK76

Centralized controller Gree CE50-24/E

Centralized controller Gree CE50-24/E
